HDPE Uniaxial Geogrid

Product Introduction

HDPE Unixial geogrid is a high-strength geomaterial that uses a polymer as the main raw materials, adds a certain degree of anti-UV, anti-aging agent after stretched in one direction so as to enable the scattered distribution of chain-shaped molecules re-oriented to lines state. HDPE Uniaxial geogrid owns much better performances than the traditional or existing reinforced materials, it is a very good reinforced composite materials.

HDPE Uniaxial Geogrid

HDPE Uniaxial Geogrid

Product Function

It’s a kind of high strength geomaterial which has been applied in highway, railway, building area, etc. It has the characteristics as following:

1 Enlarge road loading, lasting the life of road

2 Bear the greatest loading change

3 Prevent the road from cracks and deformation

4 Reduce the protection fares

5.Convenient construction, low costs

HDPE Uniaxial Geogrid

Specification

Property

Test Method

TGDG 50

TGDG 60

TGDG 80

TGSB 100

TGSB 120

TGSB 160

Ultimate Tensile Strength(KN/M)

KN/M

ASTM D 6637

50

60

80

100

120

160

Ultimate Tensile Strength

%

10

Tensile Strength at 2% Elongation

KN/M

14

16

23

29

35

47

Tensile Strength at 5% Elongation

KN/M

47

31

44

55

65

85

Creep Limit Strength

KN/M

21

24

31

39

46

60

Minimum Carbon Black

%

ASTM D 4218

2

Roll Length(M)



50

Roll Width(M)



1/2/3
