PP Biaxial Geogrid current location:Home > Product

PP Biaxial Geogrid

PP Biaxial Geogrid

PP Biaxial Geogrid

Product Introduction

The properties of Biaxial Geogrids, made in Polypropylene (PP) with their square apertures, high tensile strength and optimised geometry of nodes and ribs make them equal to any other similar material. The reinforcing action of PP Biaxial Geogrids lies mainly in confining soil and increasing its shearing resistance by a process of interlocking between the square ribs and the soil. The load dispersal effect from the interlocking mechanism is highly effective and can reduce sub-base thickness and construction cost. PP Biaxial Geogrids can be used with any kind of mechanical fill material.  Two aperture size ranges are available for optimum matching with project fill.

Product Function

1.Pavement Subgrade Stabilization

2.Area/Ground Stabilization

3.Pavement Base Reinforcement

4.Working & Load Transfer Platforms

5.Rail Track-bed Stabilization

6.Reinforced Granular Foundation Beds

PP Biaxial Geogrid PP Biaxial Geogrid

Specification

Property

Test Method

TGSB15-15

TGSB20-20

TGSB30-30

TGSB40-40

TGSB50-50

TGSB60-60

Ultimate Tensile Strength(1)(KN/M)

MD

EN ISO 10139

15

20

30

40

50

60

CD

15

20

30

40

50

60

Elongation at Maximum Load(%)

MD

13

CD

13

Tensile Strength at 2% Elongation(KN/M)

MD

 5

7.5

10.5

14

18

27.5

CD

5

7.5

10.5

14

18

27.5

Tensile Strenght at 5% Elongation(KN/M)

MD



7

14

21

28

35

48

CD

7

14

21

28

35

48

Minimum Carbon Black

%

ASTM4218



Roll Length(M)



100/75/50

Roll Width(M)



2/3.9/3.95/5/5.9/6

PP Biaxial Geogrid PP Biaxial Geogrid

PP Biaxial Geogrid PP Biaxial Geogrid

PP Biaxial Geogrid PP Biaxial Geogrid

PP Biaxial Geogrid 2017-7-14 This article is read 813 times
nex:Long FiberPre:PP Uniaxial Geogrid
