Fiberglass Polyester Paving Mat current location:Home > Product

Fiberglass Polyester Paving mat

Fiberglass Polyester Paving mat

Fiberglass Polyester Paving mat

Fiberglass Polyester Paving mat is produced from the mixture of polyester fiber and glass fiber by wet lay-out process.The combination of glass fiber and polyester fiber is the key to its performance. After mixing the two fibers together, the polyester fiberglass mat keeps good features of both fibers and minimizes shortcomings of both fibers.

Paving Mat have the structure of Polyester Mat + Fiberglass Scrim + Fiberglass Mat. The strong fiberglass mesh embedded between polyester mat and fiberglass mat is the key to its performance, the bottom side of fiberglass mat minimized the mat shrinkage during the overlay process, the polyester mat on the up side minimized the possibility of the paving mat be punctured by some sharp object, as this material being reinforced by fiberglass mesh, the composite paving mat have strong tensile strength and low elongation these features extends the life of pavement overlays through the delay of reflective cracking. The composite Paving Mat provides the highest tensile strength at elongation lower than 5%, making it the strongest,commercially available, full coverage paving mat or fabric.

Function:

1. Provide reliable waterproofing effect

Fiberglass polyester paving cloth does not shrink when immersed with high temperature bitumen. So it forms a continuous complete indeformable waterproofing layer, which can prevent water from leaking.

2.Anti-crack

Fiberglass polyester paving cloth has low shrinkage rate and high tensile strength. When immersed with bitumen, it can effectively disperse the stress in the combination area, prolong the service life of road and lower the maintenance costs.

3. Recyclable

The main raw material for fiberglass polyester paving cloth is chopped glass fiber and polyester fiber, with isotropic structure. Unlike the common textile structures, it can easily be crushed and recycled. Moreover, this material is environment friendly.

Specification

Item

Unit

Specitication

Test Method

Area Weight

g/m2

125±5

ASTM D5261

Fibergalss Content

%

≥60

PASS

Polyester Content

%

<40

PASS

Binder Content

%

≥20

PASS

Tensile Stength MD

N/50mm

≥250

ASTM D5035

Tensile Strength CD

N/50mm

≥250

ASTM D5035

Thickness

mm

≥0.8

PASS

Elongation MD

Percent

<5

ASTM D2035

Elongation CD

Percent

<5

ASTM D5035

Melting Point

°C

>230

ASTM D276

Test Condition

Ambient Temperature

20°C

65%
