Glass woven rovings

Glass woven rovings

Glass woven rovings

Product Description

◎ Glass woven rovings are bidirectional fabric made by direct rovings in plain weave pattern.

◎ Compatible with unsaturated polyester,vinylresin ,epoxy resin.

◎ Applicable for hand lay-up, winding and compress molding process,Suitable for manufacturing tank,boat,automobile parts and other FRP products.

Characteristics

◎ Consistent thickness and excellent surface treatment.

◎ Rapid impregnating and good compatibility with resin.

◎ Uniform tension,high dimensional stability and making handing easy.

◎ Good mechanical properties and high strength of parts.

Packaging&Storage

Eech roll is packed by polyester bag,and then put into a cardboard box or plastic wowen bag.The weight of each roll is between 20 to 85 Kg, The rolls are to be horizontally placed and could be in bulk or on pallet.Optimum storage conditions are between the temperature of 5~35℃ and with the humidity between 35%~65%.The product should be used within 12 months from the time of delivery and remain in theiroriginal packaging until just prior to use.

Specification

<style type="text/css"><!--
.STYLE1 {
font-family: Arial;
font-weight: bold;
}
.STYLE2 {font-family: Arial}
--></style>

Style

Yarn(Tex)

Density(ends/10cm)

Mass(g/m2)

Width(cm)

Tensile strength(N/50mm)

Warp

Weft

Warp

Weft

EWR200

200

50

50

200±16

90/100

≥1300

≥1100

ERW400

600

35

32

400±32

100/127

≥2500

≥2200

EWR570

1150

26

24

570±45

100/127

≥3600

≥3300

EWR600

1200

26

24

600±48

100/127

≥4000

≥3850

EWR800

2400

18

16

800±64

100/127

≥4600

≥4400

CWR135

150

50

40

135±10

90/100

≥750

≥600

CWR180

200

50

50

200±16

90/100

≥1150

≥1000

CWR290

450

35

30

290±22

90/100

≥1500

≥1400

CWR310

500

35

28

310±24

90/100

≥1600

≥1500

CWR330

500

35

31

3300±26

90/100

≥1700

≥1600

CWR350

500

35

35

350±28

90/100

≥1800

≥1700

CWR400

500

40

40

400±32

90/100

≥2000

≥1900

CWR600

1200

26

24

600±48

100/127

≥2750

≥2600

CWR800

2400

18

16

800±61

100/127

≥3000

≥2900

Note: Nonstandard product is available upon customer’s request.This data is for reference only.
