Fiberglass Geogrid

Fiberglass Geogrid

Product Introduction

Fiberglass geogrid is a kind of new favorable earthwork base material to strengthen the road surface and roadbed. This product is made by weaving and covering fiberglass filament. It is featured by high vertical and horizontal tensile strength, low unit extension, high favorable property of alkali resistance and aging resistance.

Product Function

1. Maintenance of old asphalt road reinforcement of asphalt pavement.

2. Converting old cement concrete road into composite road.

3. Restraining reflection cracking caused by block shrinkage.

4. Preventing and controlling the cracking caused by new and old combination and uneven settlement.

5. Road extension.

6. Reinforcement of soft soil foundation and overall strength of roadbed.

Fiberglass Geogrid Fiberglass Geogrid

Fiberglass Geogrid Fiberglass Geogrid

Specification

Property

Test Method

TGSB30-30

TGSB40-40

TGSB50-50

TGSB60-60

TGSB70-70

TGSB80-80

TGSB90-90

TGSB100-100

TGSB120-120

TGSB130-130

Ultimate Tensile Strength(1)(Kn/m)

MD

EN ISO 10139

30

40

50

60

70

80

90

100

120

130

CD

30

40

50

60

70

80

90

100

120

130

Elongation at Maximum Load(%)

MD

3

CD

3

Approximate Mesh Size(mm)

12.7*12.7  25.4*25.4  40*40

Roll Width(m)



1-6

Roll Length(m)



50-200
